Aiguille industrielle · UY 154 GAS
UY 154 GAS RG Chromium
UY 154 GAS
RG
Chromium
13
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Flat shank at 270° Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 55/7 | 706172 | — | 100 pièces | 0.665 g |
| 60/8 | 752762 | — | 100 pièces | 0.663 g |
| 65/9 | 720972 | — | 100 pièces | 0.848 g |
| 70/10 | 720982 | — | 100 pièces | 0.869 g |
| 75/11 | 706202 | — | 100 pièces | 0.878 g |
| 80/12 | 706212 | — | 100 pièces | 0.823 g |
| 90/14 | 706222 | — | 100 pièces | 0.796 g |
| 100/16 | 706232 | — | 100 pièces | 0.703 g |
| 110/18 | 720992 | — | 100 pièces | 0.827 g |
| 120/19 | 706252 | — | 100 pièces | 0.737 g |
| 125/20 | 706262 | — | 100 pièces | 0.747 g |
| 140/22 | 706272 | — | 100 pièces | 0.965 g |
| 150/ | 748792 | — | 100 pièces | 0.784 g |
Caractéristiques techniques
| Shank diameter | 2.01 mm |
|---|---|
| Length butt to eye | 31.5 mm |
| Coating | Chromium |
| Needle form | M |
| Needle form description | M1 – Curved needle with one flat on the shank |
| Canu point | R |
| Canu designation | 06:60 |
| Catalog designation | 315201MC01RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Overlock stitch |
| Stitch type class | 500 |
| Special(s) | Flat shank at 270° |
| Point style | RG - Cloth point |
| Needle system | UY 154 GAS |
| Needle system family | UY 154 |
| Variant | GAS |
| Customary needle designations | UYX 154 GAS |
| System designation 2 | UY 154 |
| System designation 3 | SY 1431 |
| System designation 4 | 42320 |
| System designation 5 | UY154GAS |
