Aiguille industrielle · UY 147 GKS
UY 147 GKS R Chromium
UY 147 GKS
R
Chromium
2
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Jeans, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 125/20 | 746982 | 48 mm | 100 pièces | 0.879 g |
| 140/22 | 746612 | 48 mm | 100 pièces | 0.951 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 42.7 mm |
| Overall length | 48 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Catalog designation | 427200BC02R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Woven fabrics |
| Examples of use | Jeans, Trousers |
| Point style | R - Cloth point |
| Needle system | UY 147 GKS |
| Needle system family | UY 147 |
| Variant | GKS |
| Pack standard | N-S-00018 – Packaging 9 |
