Aiguille industrielle · UY 143 GS
UY 143 GS R Chromium
UY 143 GS
R
Chromium
4
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Paper, Woven material with polypropylene Examples of use: Feed bags, Transport bags, Nets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 170/ | 705902 | 50.3 mm | 100 pièces | 1.325 g |
| 200/25 | 705912 | 50 mm | 100 pièces | 1.204 g |
| 230/26 | 705922 | 50 mm | 50 pièces | 1.51 g |
| 250/27 | 705932 | 50 mm | 50 pièces | 1.8 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 42.1 mm |
| Shank length | 14 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 45:30 |
| Catalog designation | 421200BC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Bag closing |
| Stitch type class | 400 |
| Recommended for | Paper, Woven material with polypropylene |
| Examples of use | Feed bags, Transport bags, Nets |
| Point style | R - Cloth point |
| Needle system | UY 143 GS |
| Needle system family | UY 143 |
| Variant | GS |
| Customary needle designations | DNX1 |
| System designation 2 | UOX 143 G |
| System designation 3 | UYX 143 GS |
| System designation 4 | 92X1 |
| System designation 5 | MY 1013 |
| System designation 6 | 1286 |
| System designation 7 | SY 4261 |
