Aiguille industrielle · UY 128 GHS
UY 128 GHS FFG Chromium
UY 128 GHS
FFG
Chromium
3
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 75/11 | 705172 | 44.6 mm | 100 pièces | 0.938 g |
| 80/12 | 705182 | 44.6 mm | 100 pièces | 0.959 g |
| 90/14 | 705192 | 44.6 mm | 100 pièces | 0.981 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Overall length | 44.6 mm |
| Shank length | 16.5 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SES |
| Canu designation | 39:55 |
| Catalog designation | 389200BC02FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | FFG - Cloth point |
| Needle system | UY 128 GHS |
| Needle system family | UY 128 |
| Pack standard | N-S-00017 – Standard Packaging |
