Aiguille industrielle · B 67
B 67 R Chromium
B 67
R
Chromium
3
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 700872 | 44.1 mm | 100 pièces | 0.882 g |
| 90/14 | 700882 | 44.1 mm | 100 pièces | 0.925 g |
| 100/16 | 700892 | 44.1 mm | 100 pièces | 0.897 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 37.8 mm |
| Overall length | 44.1 mm |
| Shank length | 13.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 31:28 |
| Catalog designation | 378200AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Stitch type class | 400 |
| Point style | R - Cloth point |
| Needle system | B 67 |
| Needle system family | B 67 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | SMX67 |
