Aiguille industrielle · B 63 SAN 10
B 63 SAN 10 FG Chromium
B 63 SAN 10
FG
Chromium
1
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Elastic fabrics Examples of use: Lace, Underwear, Bandages
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 764042 | — | 100 pièces | 0.863 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Needle size Asia | 10 |
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SUK |
| Special application needle | SAN10 – SAN™ 10 for the processing of fine knitware and woven |
| Canu designation | 35:41 |
| Catalog designation | 389200BC29FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Recommended for | Elastic fabrics |
| Examples of use | Lace, Underwear, Bandages |
| Needle size | 70 Nm |
| Point style | FG - Cloth point |
| Needle system | B 63 SAN 10 |
| Needle system family | B 63 |
| Variant | SAN 10 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DVX63 SAN 10 |
| System designation 2 | 1280 KSP SAN 10 |
| System designation 3 | DVX1 SAN 10 |
