Aiguille industrielle · B 63

B 63 RG GEBEDUR™

B 63 RG GEBEDUR™
SystèmeB 63
PointeRG
FinitionGEBEDUR™
Tailles2

Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
70/10 774262 43.7 mm 100 pièces 0.877 g
75/11 774272 43.7 mm 100 pièces 0.888 g

Caractéristiques techniques

Shank diameter2 mm
Length butt to eye38.9 mm
Overall length43.7 mm
Shank length13.5 mm
CoatingGEBEDUR™
Needle formB
Needle form descriptionB1 – Straight needle with double groove and scarf
Canu pointR
Canu designation35:40
Catalog designation389200BD10RG
Further point designationsSTU
Further point designations 02STUB
Further point designations 03S BALL
Further point designations 04SET RT
Further point designations 05EH
Further point designations 06H SET
Further point designations 07NEW RD
Further point designations 08R STU
Technical sewing applicationDouble chain stitch, Cover chain stitch
Stitch type class400, 600
Recommended forFine knitwear, Woven fabrics, Thin leather
Examples of useShirts, Blouses, Trousers
Point styleRG - Cloth point
Needle systemB 63
Needle system familyB 63
Pack standardN-S-00017 – Standard Packaging
Customary needle designationsDVX63
System designation 21280 KSP
System designation 3UY 121 GAS
System designation 4RMX63
System designation 5SY 7270
