Aiguille industrielle · B 63

B 63 RG Chromium

SystèmeB 63

PointeRG

FinitionChromium

Tailles11

Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
60/8	774142	43.7 mm	100 pièces	0.855 g
65/9	774152	43.7 mm	100 pièces	0.866 g
70/10	774162	43.7 mm	100 pièces	0.877 g
75/11	774172	43.7 mm	100 pièces	0.888 g
80/12	774182	43.7 mm	100 pièces	0.899 g
90/14	774192	43.7 mm	100 pièces	0.921 g
100/16	774202	43.7 mm	100 pièces	0.943 g
110/18	774212	43.7 mm	100 pièces	0.965 g
120/19	774222	43.7 mm	100 pièces	0.987 g
130/21	774232	43.7 mm	100 pièces	1.009 g
140/22	774242	43.7 mm	100 pièces	1.031 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.9 mm
Overall length	43.7 mm
Shank length	13.5 mm
Coating	Chromium
Needle form	B
Needle form description	B1 – Straight needle with double groove and scarf
Canu point	R
Canu designation	35:40
Catalog designation	389200BC10RG
Further point designations	STU
Further point designations 02	STUB
Further point designations 03	S BALL
Further point designations 04	SET RT
Further point designations 05	EH
Further point designations 06	H SET
Further point designations 07	NEW RD
Further point designations 08	R STU
Technical sewing application	Double chain stitch, Cover chain stitch
Stitch type class	400, 600
Point style	RG - Cloth point
Needle system	B 63
Needle system family	B 63
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DVX63
System designation 2	1280 KSP
