Aiguille industrielle · B 63
B 63 FFG GEBEDUR™
B 63
FFG
GEBEDUR™
5
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 60/8 | 774542 | 43.7 mm | 100 pièces | 0.855 g |
| 70/10 | 774382 | 43.7 mm | 100 pièces | 0.877 g |
| 75/11 | 774392 | 43.7 mm | 100 pièces | 0.888 g |
| 80/12 | 774402 | 43.7 mm | 100 pièces | 0.899 g |
| 90/14 | 774412 | 43.7 mm | 100 pièces | 0.921 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Overall length | 43.7 mm |
| Shank length | 13.5 mm |
| Coating | GEBEDUR™ |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SES |
| Canu designation | 35:40 |
| Catalog designation | 389200BD10FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double chain stitch, Cover chain stitch |
| Stitch type class | 400, 600 |
| Point style | FFG - Cloth point |
| Needle system | B 63 |
| Needle system family | B 63 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DVX63 |
| System designation 2 | 1280 KSP SES |
| System designation 3 | UY 121 GAS |
| System designation 4 | RMX63 |
| System designation 5 | SY 7270 |
