Aiguille industrielle · B 63

B 63 FFG Chromium

SystèmeB 63

PointeFFG

FinitionChromium

Tailles7

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
60/8	774292	43.7 mm	100 pièces	0.855 g
70/10	774312	43.7 mm	100 pièces	0.877 g
75/11	774322	43.7 mm	100 pièces	0.888 g
80/12	774332	43.7 mm	100 pièces	0.899 g
90/14	774342	43.7 mm	100 pièces	0.921 g
100/16	774352	43.7 mm	100 pièces	0.943 g
110/18	774362	43.7 mm	100 pièces	0.965 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.9 mm
Overall length	43.7 mm
Shank length	13.5 mm
Coating	Chromium
Needle form	B
Needle form description	B1 – Straight needle with double groove and scarf
Canu point	SES
Canu designation	35:40
Catalog designation	389200BC10FFG
Further point designations	SES
Further point designations 02	L BALL
Further point designations 03	J BALL
Further point designations 04	SIN
Further point designations 05	NYR
Further point designations 06	BPL
Further point designations 07	TB
Further point designations 08	B
Further point designations 09	R K
Technical sewing application	Double chain stitch, Cover chain stitch
Stitch type class	400, 600
Point style	FFG - Cloth point
Needle system	B 63
Needle system family	B 63
Pack standard	N-S-00017 – Standard Packaging
System designation 2	1280 KSP SES
System designation 3	UY 121 GAS
System designation 5	SY 7270
