Aiguille industrielle · B 29

B 29 RG Chromium

B 29 RG Chromium
SystèmeB 29
PointeRG
FinitionChromium
Tailles8

Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
70/10 700242 34.4 mm 100 pièces 0.765 g
75/11 753992 — 100 pièces 0.59 g
80/12 700252 34.4 mm 100 pièces 0.781 g
90/14 700262 34.4 mm 100 pièces 0.795 g
100/16 700272 34.4 mm 100 pièces 0.805 g
110/18 700282 34.4 mm 100 pièces 0.634 g
120/19 700292 34.4 mm 100 pièces 0.844 g
130/21 741502 34.4 mm 100 pièces 0.865 g

Caractéristiques techniques

Shank diameter2.02 mm
Length butt to eye28.6 mm
CoatingChromium
Needle formB
Needle form descriptionB1 – Straight needle with double groove and scarf
Canu pointR
Canu designation03:69
Catalog designation286202BC03RG
Further point designationsSTU
Further point designations 02STUB
Further point designations 03S BALL
Further point designations 04SET RT
Further point designations 05EH
Further point designations 06H SET
Further point designations 07NEW RD
Further point designations 08R STU
Technical sewing applicationOverlock stitch
Stitch type class500
Point styleRG - Cloth point
Needle systemB 29
Needle system familyB 29
Pack standardN-S-00017 – Standard Packaging
Customary needle designationsRMX29
System designation 281X5
System designation 3UY 3029 GS
System designation 4SY 6125
System designation 5B29 A
