Aiguille industrielle · B 29
B 29 FG Chromium
B 29
FG
Chromium
4
Point style FG - Cloth point Medium ball point • Round point with medium ball • Suitable for loose-knit fabrics, elastic material and material containing rubber or elastane Coating Chromium Needle with standard chrome coating. Recommended for: Elastic fabrics Examples of use: Lace, Underwear, Bandages
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 700312 | — | 100 pièces | 0.77 g |
| 80/12 | 700322 | 34.4 mm | 100 pièces | 0.785 g |
| 90/14 | 700332 | 34.4 mm | 100 pièces | 0.802 g |
| 100/16 | 741522 | 34.4 mm | 100 pièces | 0.804 g |
Caractéristiques techniques
| Shank diameter | 2.02 mm |
|---|---|
| Length butt to eye | 28.6 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | SUK |
| Canu designation | 03:69 |
| Catalog designation | 286202BC03FG |
| Further point designations | SUK |
| Further point designations 02 | B BALL |
| Further point designations 03 | M BALL |
| Further point designations 04 | SI |
| Further point designations 05 | BPM |
| Further point designations 06 | LAC |
| Further point designations 07 | R SUK |
| Further point designations 08 | U |
| Further point designations 09 | R KB |
| Technical sewing application | Overlock stitch |
| Stitch type class | 500 |
| Point style | FG - Cloth point |
| Needle system | B 29 |
| Needle system family | B 29 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | RMX29 B |
| System designation 2 | 81X5 SUK |
| System designation 3 | UY 3029 GS |
| System designation 4 | SY 6125 |
| System designation 5 | B29 A SES |
