Aiguille industrielle · B 27

B 27 RS Chromium

B 27 RS Chromium
SystèmeB 27
PointeRS
FinitionChromium
Tailles4

Point style RS - Cloth point Sharp round point • Very slim and sharp point • Suitable for fine densely-woven fabrics • Standard point for blind stitch and Schiffli embroidery • Exact piercing of the material • Perfectly suited for very straight lockstitch seams Coating Chromium Needle with standard chrome coating. Recommended for: Straight lockstitch seams on fine woven fabrics Examples of use: Blouses, Fine skirts, Trousers, Draperies

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
55/7 779442 33.1 mm 100 pièces 0.728 g
60/8 771422 33.1 mm 100 pièces 0.765 g
80/12 751742 33.1 mm 100 pièces 0.784 g
100/16 751762 33.1 mm 100 pièces 0.806 g

Caractéristiques techniques

Shank diameter2.02 mm
Length butt to eye28.6 mm
Overall length33.1 mm
Shank length10 mm
CoatingChromium
Needle formB
Needle form descriptionB1 – Straight needle with double groove and scarf
Canu pointSPI
Canu designation03:36
Catalog designation286202BC01RS
Further point designationsR-SPI
Further point designations 02S SET
Further point designations 03SPI
Further point designations 04R-SP
Technical sewing applicationOverlock stitch
Stitch type class500
Recommended forStraight lockstitch seams on fine woven fabrics
Examples of useBlouses, Fine skirts, Trousers, Draperies
Point styleRS - Cloth point
Needle systemB 27
Needle system familyB 27
Pack standardN-S-00017 – Standard Packaging
Customary needle designationsDCX1 SPI
System designation 2DCX27 SPI
System designation 3DMX1 SPI
System designation 4MY 1023 SPI
System designation 5RMX27 SPI
System designation 681X1 SPI
System designation 782X1 SPI
System designation 8DCX27
System designation 9DCX1
System designation 1081X1
System designation 11SY 6120
