Aiguille industrielle · 805
805 LR Chromium
805
LR
Chromium
4
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Special(s): Flat shank at 90° Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 100/16 | 739472 | — | 100 pièces | 0.717 g |
| 110/18 | 739482 | 44 mm | 100 pièces | 0.755 g |
| 120/19 | 739492 | 44.2 mm | 100 pièces | 0.971 g |
| 140/22 | 739512 | — | 100 pièces | 0.859 g |
Caractéristiques techniques
| Shank diameter | 2.04 mm |
|---|---|
| Length butt to eye | 38.1 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 32:30 |
| Catalog designation | 381204AC01LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Flat shank at 90° |
| Point style | LR - Cutting point |
| Needle system | 805 |
| Needle system family | 805 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | SMX805 LR |
| System designation 2 | SY 7235 |
