Aiguille industrielle · 490
490 R Chromium
490
R
Chromium
5
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Mattresses, Blankets
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 754172 | 54.8 mm | 100 pièces | 1.233 g |
| 100/16 | 734212 | 54.8 mm | 100 pièces | 1.256 g |
| 110/18 | 747342 | 54.8 mm | 100 pièces | 1.254 g |
| 120/19 | 734232 | 54.8 mm | 100 pièces | 1.269 g |
| 140/22 | 753572 | 54.8 mm | 100 pièces | 1.37 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 49 mm |
| Overall length | 54.8 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 49:05 |
| Catalog designation | 490200AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Quilting |
| Stitch type class | 300 |
| Recommended for | Woven fabrics |
| Examples of use | Mattresses, Blankets |
| Point style | R - Cloth point |
| Needle system | 490 |
| Needle system family | 490 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | EBX1 |
| System designation 2 | 490 |
| System designation 3 | 860 |
| System designation 4 | 2331 |
| System designation 5 | SY 7660 |
