Aiguille industrielle · 46X1
46X1 RS Chromium
46X1
RS
Chromium
2
Point style RS - Cloth point Sharp round point • Very slim and sharp point • Suitable for fine densely-woven fabrics • Standard point for blind stitch and Schiffli embroidery • Exact piercing of the material • Perfectly suited for very straight lockstitch seams Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics Examples of use: Trousers, Draperies
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 733682 | 42.2 mm | 100 pièces | 0.676 g |
| 90/14 | 733702 | 42.2 mm | 100 pièces | 0.717 g |
Caractéristiques techniques
| Shank diameter | 1.28 mm |
|---|---|
| Length butt to eye | 35.3 mm |
| Overall length | 42.2 mm |
| Shank length | 15 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B – Straight needle with double groove |
| Canu point | SPI |
| Canu designation | 23:65 |
| Catalog designation | 353128BC01RS |
| Further point designations | R-SPI |
| Further point designations 02 | S SET |
| Further point designations 03 | SPI |
| Further point designations 04 | R-SP |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Recommended for | Woven fabrics |
| Examples of use | Trousers, Draperies |
| Point style | RS - Cloth point |
| Needle system | 46X1 |
| Needle system family | 46X1 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | 1571 |
| System designation 2 | POX1 |
| System designation 3 | SY 2550 |
