Aiguille industrielle · 4463 KK
4463 KK RG Chromium
4463 KK
RG
Chromium
4
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Short shank Recommended for: Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing Examples of use: Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 733282 | — | 100 pièces | 0.806 g |
| 90/14 | 733292 | 39.4 mm | 100 pièces | 0.837 g |
| 100/16 | 733302 | 39.4 mm | 100 pièces | 0.793 g |
| 110/18 | 733312 | 39.4 mm | 100 pièces | 0.69 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | B |
| Needle form description | B1 – Straight needle with double groove and scarf |
| Canu point | R |
| Canu designation | 18:63 |
| Catalog designation | 339200BC02RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double chain stitch |
| Stitch type class | 400 |
| Special(s) | Short shank |
| Recommended for | Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing |
| Examples of use | Jeans, Suits |
| Point style | RG - Cloth point |
| Needle system | 4463 KK |
| Needle system family | 4463 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | UO X 4463 |
| System designation 2 | SY 8694 |
