Aiguille industrielle · 34

34 FFG Chromium

Système34

PointeFFG

FinitionChromium

Tailles6

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
60/8	758022	38.1 mm	100 pièces	0.71 g
65/9	757492	38.1 mm	100 pièces	0.716 g
70/10	732222	38.2 mm	100 pièces	0.718 g
75/11	757582	38.3 mm	100 pièces	0.734 g
80/12	732232	38.3 mm	100 pièces	0.742 g
90/14	732242	38.4 mm	100 pièces	0.762 g

Caractéristiques techniques

Shank diameter	1.63 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	SES
Canu designation	12:05
Catalog designation	339163AC06FFG
Further point designations	SES
Further point designations 02	L BALL
Further point designations 03	J BALL
Further point designations 04	SIN
Further point designations 05	NYR
Further point designations 06	BPL
Further point designations 07	TB
Further point designations 08	B
Further point designations 09	R K
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	FFG - Cloth point
Needle system	34
Needle system family	34
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	TFX1 J
System designation 2	PFX34 J
System designation 3	16X1 SES
System designation 4	TFX3 J
System designation 5	287 SES
System designation 6	16X73 SES
System designation 7	690 SES
