Aiguille industrielle · 332
332 LL Chromium
332
LL
Chromium
7
Point style LL - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the left • Very straight seam position • Thread slightly elevated • Stitch holes largely filled • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 730892 | 45.3 mm | 100 pièces | 1.045 g |
| 100/16 | 730902 | 45.4 mm | 100 pièces | 1.095 g |
| 110/18 | 730912 | 45.4 mm | 100 pièces | 1.104 g |
| 120/19 | 730922 | 45.4 mm | 100 pièces | 1.102 g |
| 130/21 | 730942 | 45.5 mm | 100 pièces | 1.15 g |
| 140/22 | 730952 | 45.5 mm | 100 pièces | 1.206 g |
| 160/23 | 730962 | 45.6 mm | 100 pièces | 1.256 g |
Caractéristiques techniques
| Shank diameter | 1.98 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Shank length | 14.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LL |
| Canu designation | 35:15 |
| Catalog designation | 389198AC01LL |
| Further point designations | NTW |
| Further point designations 02 | TW |
| Further point designations 03 | VL |
| Further point designations 04 | TW SP |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | LL - Cutting point |
| Needle system | 332 |
| Needle system family | 332 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | DIX4 |
| System designation 2 | 022 LL |
| System designation 3 | 29X4 NTW |
| System designation 4 | 29X4 TW |
| System designation 5 | 332 LL |
| System designation 6 | SY 3750 |
