Aiguille industrielle · 287
287 LR Chromium
287
LR
Chromium
3
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thick leather Examples of use: Car seats, Cushions
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 120/19 | 729042 | 38.8 mm | 100 pièces | 0.807 g |
| 130/21 | 729052 | 38.9 mm | 100 pièces | 0.831 g |
| 140/22 | 729062 | 39 mm | 100 pièces | 0.686 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Shank length | 11.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 11:45 |
| Catalog designation | 339163AC03LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thick leather |
| Examples of use | Car seats, Cushions |
| Point style | LR - Cutting point |
| Needle system | 287 |
| Needle system family | 287 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | TFX 287 LR |
| System designation 2 | 130 B LR |
| System designation 3 | 287 H LR |
| System designation 4 | 287 L |
| System designation 5 | 287 LR |
| System designation 6 | 376 LR |
| System designation 7 | 606 LR |
| System designation 8 | 690 LR |
| System designation 9 | SY6632 |
