Aiguille industrielle · 2091
2091 FFG Chromium
2091
FFG
Chromium
4
Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Trousers, Shirts, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 80/12 | 727352 | 50.3 mm | 100 pièces | 0.984 g |
| 90/14 | 727362 | 50.3 mm | 100 pièces | 1.006 g |
| 100/16 | 727372 | 50.3 mm | 100 pièces | 1.045 g |
| 110/18 | 766802 | 50.3 mm | 100 pièces | 1.063 g |
Caractéristiques techniques
| Shank diameter | 1.74 mm |
|---|---|
| Length butt to eye | 47 mm |
| Overall length | 50.3 mm |
| Shank length | 17.5 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | SES |
| Canu designation | 47:42 |
| Catalog designation | 470174AC01FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Button sewing |
| Stitch type class | 100, 300 |
| Point style | FFG - Cloth point |
| Needle system | 2091 |
| Needle system family | 2091 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | TQX7 |
| System designation 2 | 175X7 |
| System designation 3 | 2091 LGK |
| System designation 4 | 29 L |
