Aiguille industrielle · 190
190 R Chromium
190
R
Chromium
11
Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating Chromium Needle with standard chrome coating. Recommended for: Woven fabrics, Thin leather Examples of use: Shirts, Blouses, Trousers
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 70/10 | 725822 | 49 mm | 100 pièces | 0.982 g |
| 80/12 | 725832 | 49 mm | 100 pièces | 1.008 g |
| 90/14 | 725842 | 49 mm | 100 pièces | 1.053 g |
| 100/16 | 725852 | 49 mm | 100 pièces | 1.065 g |
| 110/18 | 725862 | 49 mm | 100 pièces | 1.106 g |
| 120/19 | 725872 | 49 mm | 100 pièces | 1.139 g |
| 130/21 | 725882 | 49 mm | 100 pièces | 1.593 g |
| 140/22 | 725892 | 49 mm | 100 pièces | 1.189 g |
| 160/23 | 743752 | 49 mm | 100 pièces | 1.31 g |
| 180/24 | 757882 | 49 mm | 100 pièces | 1.386 g |
| 200/25 | 756612 | 49 mm | 100 pièces | 1.505 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 44.5 mm |
| Overall length | 49 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Canu designation | 47:25 |
| Catalog designation | 445200AC01R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Stitch type class | 300 |
| Point style | R - Cloth point |
| Needle system | 190 |
| Needle system family | 190 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | MTX 190 |
| System designation 2 | 150 SC |
| System designation 3 | 190 |
| System designation 4 | SY 7555 |
