Aiguille industrielle · 190
190 LR Chromium
190
LR
Chromium
4
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thick leather Examples of use: Car seats, Cushions
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 110/18 | 726102 | 49 mm | 100 pièces | 1.122 g |
| 120/19 | 726112 | 49 mm | 100 pièces | 1.45 g |
| 130/21 | 754912 | 49 mm | 100 pièces | 1.19 g |
| 180/24 | 766762 | 49 mm | 100 pièces | 1.2 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 44.5 mm |
| Overall length | 49 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 47:25 |
| Catalog designation | 445200AC01LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Stitch type class | 300 |
| Recommended for | Thick leather |
| Examples of use | Car seats, Cushions |
| Point style | LR - Cutting point |
| Needle system | 190 |
| Needle system family | 190 |
| Pack standard | N-S-00018 – Packaging 9 |
| Customary needle designations | MTX 190 LR |
