Aiguille industrielle · 1738 CL SAN 1
1738 CL SAN 1 RG Chromium
1738 CL SAN 1
RG
Chromium
1
Point style RG - Cloth point Normal round point with small ball • Slightly rounded shape of the point • Suitable for knitted and woven fabrics and microfiber • Standard point for chainstitch as well as single and multihead embroidery • Perfectly suited for button sewing Coating Chromium Needle with standard chrome coating. Special(s): Point groove left Recommended for: Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing Examples of use: Jeans, Suits
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 760042 | — | 100 pièces | 0.774 g |
Caractéristiques techniques
| Shank diameter | 1.63 mm |
|---|---|
| Needle size Asia | 14 |
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | R |
| Special application needle | SAN1 – SAN™ 1 for the embroidery on sturdy products (f. ex. baseball caps) |
| Catalog designation | 339163AC25RG |
| Further point designations | STU |
| Further point designations 02 | STUB |
| Further point designations 03 | S BALL |
| Further point designations 04 | SET RT |
| Further point designations 05 | EH |
| Further point designations 06 | H SET |
| Further point designations 07 | NEW RD |
| Further point designations 08 | R STU |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Point groove left |
| Recommended for | Leightweight to and medium-weight knitwear and woven fabrics, Soft leather for clothing |
| Examples of use | Jeans, Suits |
| Needle size | 90 Nm |
| Point style | RG - Cloth point |
| Needle system | 1738 CL SAN 1 |
| Needle system family | 1738 |
| Variant | CL SAN 1 |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | 1738 CL SA |
