Aiguille industrielle · 135X17

135X17 R GEBEDUR™

Système135X17

PointeR

FinitionGEBEDUR™

Tailles9

Point style R - Cloth point Normal round point • Slightly sharp point • Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather • Standard point for lockstitch Coating GEBEDUR™ Needle with titanium nitride coating for increased wear resistance. Its surface has a higher hardness compared to standard needles. This provides better protection against wear and abrasion, especially in the point and eye areas of the needle. Recommended for: Medium-weight woven fabrics, Leather for clothing, Artificial leather Examples of use: Jeans, Workwear, Suits, Accessories, Shoes, Leather clothing, Covers for upholstery

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
75/11	784862	43.2 mm	100 pièces	0.933 g
80/12	763422	43.3 mm	100 pièces	0.911 g
100/16	763262	43.5 mm	100 pièces	0.961 g
110/18	761002	43.6 mm	100 pièces	0.809 g
120/19	766722	43.7 mm	100 pièces	1.033 g
125/20	761012	44.4 mm	100 pièces	0.998 g
130/21	761022	44.4 mm	100 pièces	0.995 g
140/22	761032	44.5 mm	100 pièces	1.048 g
160/23	761992	44.7 mm	100 pièces	1.144 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.9 mm
Coating	GEBEDUR™
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Further point designations	SET
Further point designations 02	RD
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	R - Cloth point
Needle system	135X17
Needle system family	135X17
Customary needle designations	DPX17
System designation 2	135X85
System designation 3	135X535
System designation 4	2167
System designation 5	SY 3355
System designation 6	SY 3357
