Aiguille industrielle · 135X16
135X16 LR Chromium
135X16
LR
Chromium
4
Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 90/14 | 754242 | 43.4 mm | 100 pièces | 0.752 g |
| 100/16 | 718742 | 43.5 mm | 100 pièces | 0.956 g |
| 110/18 | 754262 | 43.6 mm | 100 pièces | 0.983 g |
| 120/19 | 754272 | 43.7 mm | 100 pièces | 0.963 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 38.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | LR |
| Canu designation | 37:20 |
| Catalog designation | 389200AC01LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Point style | LR - Cutting point |
| Needle system | 135X16 |
| Needle system family | 135X16 |
| Variant | RTW |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | DPX16 LR |
| System designation 2 | 135X16 NRTW |
| System designation 3 | 135X17 LR |
| System designation 4 | 135X17 LR |
| System designation 5 | 135X16 LR |
| System designation 6 | SY 3383 |
| Needle recommendation | Quality choice |
