Aiguille industrielle · 134 KK
134 KK PCL Chromium
134 KK
PCL
Chromium
4
Point style PCL -Cutting point Cutting Point • With a point groove • Cuts the leather perpendicular to the sewing direction at an angle of 90° • Creates a prominent decorative effect on thick and hard leather due to the slanted thread position • Thread very deep-set • Stitch holes largely filled by the thread • Suitable for very short stitches Coating Chromium Needle with standard chrome coating. Special(s): Short shank, Point groove left Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories
Tailles disponibles
| Taille (Nm) | Référence | Longueur totale | Conditionnement | Poids |
|---|---|---|---|---|
| 75/11 | 714252 | 38.3 mm | 100 pièces | 0.815 g |
| 90/14 | 714282 | — | 100 pièces | 0.836 g |
| 100/16 | 714292 | — | 100 pièces | 0.863 g |
| 110/18 | 714302 | 38.7 mm | 100 pièces | 0.876 g |
Caractéristiques techniques
| Shank diameter | 2 mm |
|---|---|
| Length butt to eye | 33.9 mm |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 – Straight needle with single groove and scarf |
| Canu point | P CL |
| Canu designation | 18:60 |
| Catalog designation | 339200AC06P |
| Further point designations | NWLT |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Short shank, Point groove left |
| Recommended for | Thin leather |
| Examples of use | Leather clothing, Shoes, Accessories |
| Point style | PCL -Cutting point |
| Needle system | 134 KK |
| Needle system family | 134 |
| Variant | KK |
| Pack standard | N-S-00017 – Standard Packaging |
| Customary needle designations | PFX134 KK PCL |
| System designation 2 | 134 KK PC LS |
| System designation 3 | 797 KK PCL |
| System designation 4 | SY 6761 |
