Aiguille industrielle · 134

134 FFG Chromium

Système134

PointeFFG

FinitionChromium

Tailles8

Point style FFG - Cloth point Small ball point • Round point with small ball • Suitable for fine and medium-weight knitted and woven fabrics • When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged • Perfectly suited for jersey and tricot fabrics Coating Chromium Needle with standard chrome coating. Recommended for: Fine knitwear, Woven fabrics Examples of use: Shirts, Blouses, Underwear

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
55/7	759892	38 mm	100 pièces	0.859 g
60/8	717622	38.1 mm	100 pièces	0.855 g
65/9	717632	38.1 mm	100 pièces	0.855 g
85/13	757402	38.4 mm	100 pièces	0.871 g
120/19	717702	38.8 mm	100 pièces	0.895 g
125/20	749772	38.9 mm	100 pièces	0.934 g
130/21	717712	38.9 mm	100 pièces	0.927 g
140/22	749662	39 mm	100 pièces	0.955 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	33.9 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu point	SES
Canu designation	20:05
Catalog designation	339200AC01FFG
Further point designations	SES
Further point designations 02	L BALL
Further point designations 03	J BALL
Further point designations 04	SIN
Further point designations 05	NYR
Further point designations 06	BPL
Further point designations 07	TB
Further point designations 08	B
Further point designations 09	R K
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	FFG - Cloth point
Needle system	134
Needle system family	134
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DPX5 J
System designation 2	DPX7 J
Needle recommendation	Quality choice
