Aiguille industrielle · 134-35

134-35 LR Chromium

134-35 LR Chromium
Système134-35
PointeLR
FinitionChromium
Tailles16

Point style LR - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the right • Thread: slight to moderate slant (leatherdependent), slightly elevated • Stitch holes easily visible • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories

Tailles disponibles

Taille (Nm)RéférenceLongueur totaleConditionnementPoids
70/10 717202 42.4 mm 100 pièces 0.884 g
75/11 716272 42.5 mm 100 pièces 0.879 g
80/12 717212 42.5 mm 100 pièces 0.898 g
85/13 758042 42.6 mm 100 pièces 0.711 g
90/14 717222 42.6 mm 100 pièces 0.905 g
100/16 717232 42.8 mm 100 pièces 0.916 g
110/18 717242 42.9 mm 100 pièces 0.954 g
120/19 717252 43 mm 100 pièces 0.97 g
125/20 758482 43.1 mm 100 pièces 0.993 g
130/21 717262 43.1 mm 100 pièces 0.995 g
140/22 717272 43.2 mm 100 pièces 1.03 g
150/ 717282 43.4 mm 100 pièces 1.106 g
160/23 717292 43.5 mm 100 pièces 1.095 g
170/ 717302 43.6 mm 100 pièces 1.154 g
180/24 717312 43.7 mm 100 pièces 1.155 g
200/25 717322 44 mm 100 pièces 1.216 g

Caractéristiques techniques

Shank diameter2 mm
Length butt to eye38.1 mm
CoatingChromium
Needle formA
Needle form descriptionA1 – Straight needle with single groove and scarf
Canu pointLR
Canu designation32:10
Catalog designation381200AC01LR
Further point designationsNRTW
Further point designations 02RTW
Technical sewing applicationDouble lock stitch
Stitch type class300
Point styleLR - Cutting point
Needle system134-35
Needle system family134-35
Customary needle designationsDPX35 LR
System designation 2DPX35 VR
System designation 3134-35 LRS
System designation 4134-35 VR
System designation 52134-35 LR
System designation 62134-35 VR
System designation 7SY 7229
