Aiguille industrielle · 134-35

134-35 LL Chromium

Système134-35

PointeLL

FinitionChromium

Tailles9

Point style LL - Cutting point Cutting point • Cuts the leather in the sewing direction at an angle of 45°, slanted to the left • Very straight seam position • Thread slightly elevated • Stitch holes largely filled • Suitable for short to medium stitches Coating Chromium Needle with standard chrome coating. Recommended for: Thin leather Examples of use: Leather clothing, Shoes, Accessories

Tailles disponibles

Taille (Nm)	Référence	Longueur totale	Conditionnement	Poids
85/13	783782	42.6 mm	100 pièces	0.91 g
90/14	758292	42.6 mm	100 pièces	0.909 g
100/16	758302	42.8 mm	100 pièces	0.926 g
110/18	758312	42.9 mm	100 pièces	0.954 g
120/19	758322	43 mm	100 pièces	0.98 g
130/21	758332	43.1 mm	100 pièces	1.009 g
140/22	758342	43.2 mm	100 pièces	1.04 g
150/	777032	43.4 mm	100 pièces	1.064 g
160/23	758352	43.5 mm	100 pièces	1.114 g

Caractéristiques techniques

Shank diameter	2 mm
Length butt to eye	38.1 mm
Coating	Chromium
Needle form	A
Needle form description	A1 – Straight needle with single groove and scarf
Canu designation	32:10
Catalog designation	381200AC01LL
Further point designations	NTW
Further point designations 02	TW
Further point designations 03	VL
Further point designations 04	TW SP
Technical sewing application	Double lock stitch
Stitch type class	300
Point style	LL - Cutting point
Needle system	134-35
Needle system family	134-35
Pack standard	N-S-00017 – Standard Packaging
Customary needle designations	DPX35 LL
System designation 2	134-35 LLS
System designation 3	2134-35 LL
Needle recommendation	Quality choice
